Shell and Tube Heat
Liên hệ
Our Type 500 Tube and Shell heat exchanger remains the industry standard in ultimate value and long-term reliability. This proven fixed tubesheet shell and tube heat exchanger offers the cost effectiveness that comes with having a highly standardized design, while easily providing various options to meet specific customer requirements.
Our Type 500 Tube and Shell heat exchanger remains the industry standard in ultimate value and long-term reliability. This proven fixed tubesheet shell and tube heat exchanger offers the cost effectiveness that comes with having a highly standardized design, while easily providing various options to meet specific customer requirements.
PERFORMANCE NOTES.
- Pre-engineered components
- Many readily available designs
- Available in straight tube or u-tube bundles; removable and non-removable
SPECIFICATIONS.
| Sizes | 3″ to 12″ diameter; 14″ to 120″ length | |
| Shells | Carbon Steel or 304 Stainless Steel | |
| Tubes | 1/4″, 3/8″ or 5/8″ diameter tubes available in Copper, Admiralty, 90/10 CuNi, or 304 S/S. Straight tube or U-Tube configurations |
|
| Baffles | Precision punched Carbon Steel, Brass or 304 S/S |
|
| Heads | Cast heads available in iron, 304 S/S, or bronze; Fabricated heads available in Steel, 304 S/S, or 90/10 CuNi. |
|
| Flow | Available in 1-pass, 2-pass, and 4-pass designs | |
| Codes | Commercial Standard (non-code) ASME TEMA-C |
|
